ESPECIFICACIONES TECNICAS:

1. System.-
•Main Processor Embedded processor
•Operating System Embedded linux

2. SMD Plus.-
•Performance 4 channels
•AI Search Search by target classification (Human, Vehicle)

3. Video and Audio.-
•Analog Camera Input 4 channels, BNC
•HDCVI Camera Input 5MP, 4MP, 1080p@ 25/30 fps, 720p@ 50/60 fps, 720p@
25/30 fps
•AHD Camera Input 5MP, 4MP, 1080p@ 25/30 fps, 720p@ 25/30 fps
•TVI Camera Input 5MP, 4MP, 1080p@25/30 fps, 720p@25/30 fps
•CVBS Camera Input PAL/NTSC
•IP Camera Input 4+2 channels, each channel up to 6MP
•Audio In/Out 1/1, RCA
•Two-way Talk Reuse audio in/out, RCA

4. Recording.-
•Compression AI Coding/H.265+/H.265/H.264+/H.264
•Resolution 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
•Record Rate:
-Main stream: All channel 5M-N (1 fps-10 fps); 4M-N/1080p (1 fps-15 fps); 1080N/720p/960H/ D1/CIF (1 fps-25/30 fps)
-Sub stream: D1/CIF (1 fps-15 fps)
•Bit Rate 32 kbps-6144 kbps per channel
•Record Mode: Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop
•Record Interval 1 min- 60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s-300 s
•Audio Compression G.711A; G.711U; PCM
•Audio Sample Rate 8 KHz, 16 bit per channel
•Audio Bit Rate 64 kbps per channel

5. Display.-
•Interface 1 HDMI; 1 VGA
•Resolution 1920 × 1080, 1280 × 1024, 1280 × 720
•Multi-screen Display When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/6
•OSD Camera title; Time; Video loss; Camera lock; Motion detection; Recording

6. Network.-
•Interface 1 RJ-45 Port (100 MB)
•Network Function: http; https; TCP/IP; IPv4/IPv6; Wi-Fi; 3G/4G; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
•Max. User Access 128 users
•Smart Phone iPhone; iPad; Android
•Interoperability ONVIF 16.12, CGI Conformant

7. Video Detection and Alarm.-
•Trigger Events Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips
•Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
•Alarm input N/A
•Relay Output N/A

8. Playback and Backup.-
•Playback 1/4
•Search Mode Time/Date, Alarm, MD and Exact Search (accurate to second)
•Playback Function: Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom
•Backup Mode USB Device/Network

9. Storage.-
•Internal HDD 1 SATA port, up to 6 TB capacity
•eSATA N/A

10. Auxiliary Interface.-
•USB 2 USB ports (USB 2.0)
•RS485 N/A
•RS232 N/A

11. Electrical.-
•Power Supply DC 12V/1.5A
•Power Consumption (Without HDD) < 4W

12. Construction.-
•Dimensions Cooper 1U, 198.3 mm × 203.4 mm × 41.5 mm (7.81'' × 8.01'' × 1.63'')
•Net Weight (without HDD) 0.55 kg (1.2 lb)
•Gross Weight 1.02 kg (2.25 lb)
•Installation Desktop installation

13. Environmental.-
•Operating Conditions -10°C to +45°C (+14°F to +113°F), 0%-90% (RH)
•Storage Conditions -20°C to +70°C (-4°F to +158°F), 0%-90% (RH)

14. Third-party Support.-
•Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more

15. Certifications.-
•Certifications
-FCC: Part 15 Subpart B
-CE: CE-LVD: EN 60950-1/IEC 60950-1
-CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130; EN 55024
